Connectors

For connection to high current cables

Magnaflux connectors enable fast, secure, and durable electrical connections between 4/0 cables and MPI equipment—wet benches, power packs, and mobile units. Featuring heavy-duty lug and quick-connect terminals, they reduce resistance, heat, and setup time while improving current flow and operator safety.

Features

Standard 4/0 lug terminals for robust cable attachment
Quick‑Connect system (QC‑M male and QC‑F female) with twist-lock ease
Lug-to-QC adapter set for compatibility between connector types
Designed for lower resistance, reduced heat, and longer life than legacy connectors

Applications

Fast, field‑friendly setup on mobile MPI power packs
Reliable connections for high‑current AC/DC inspections
Versatile connectivity in workshops or distant job sites
Adapts existing lug‑terminated cables to quick‑connect systems

Technical Data

Connector Type	Description
Standard Lug	4/0 cable termination lug (PN 626342)
Quick‑Connect Male (QC‑M)	4/0 cable termination, mates with QC‑F (PN 628829)
Quick‑Connect Female (QC‑F)	Mates with QC‑M (PN 628828)
Lug‑to‑QC Adapter Set	Includes one lug→QC‑M and one lug→QC‑F adapter (PN 628832)
Connector Resistance	~50% less than legacy “either-end” connectors
