Echogel

Economical Ultrasonic couplant

Echogel 20 is an economical, medium‑viscosity ultrasonic couplant formulated for inspections where corrosion or salt cake is present. It provides reliable moisture retention, excellent surface wetting, and corrosion inhibition—ideal for flaw detection, sizing, and thickness gauging on salt‑caked or corroded components. It’s silicone‑free and suitable even for hydrogen embrittlement testing environments.

Features

Superior surface wetting for oily or dirty surfaces
Maintains viscosity on corroded or salt‑caked surfaces
Effective corrosion inhibition
Silicone‑free formulation
Compatible with hydrogen embrittlement testing

Applications

Flaw detection
Flaw sizing
Thickness gauging
Weld inspection
Power‑generating boilers
Pipes, tubular goods, OCTG, connections, couplings
High‑strength steel components
Small‑diameter and large‑volume inspections where corrosion or salt cake exists

Technical Data

Property	Specification
Viscosity	5.5 (Medium-thick gel)
NDT Method	Ultrasonic Testing
Compatible Substrates	Most metals and composite materials
Temperature Range	–3 °C to 60 °C (27 °F to 140 °F)
Corrosion Resistance	Good
Silicone	None
Regulatory Standards	API, ASME, ASTM F519, AWS
Packaging Sizes	1 gal (3.78 L), 5 gal (18.9 L), 55 gal (208 L)
