Radioactive Source

Industrial Gamma Radiography Sources

Iridium and Cobalt Isotopes are sealed radioactive sources engineered for use in industrial gamma radiography, offering high penetration power and stable emission characteristics for non-destructive testing of dense materials. These isotopes, specifically Iridium-192 and Cobalt-60, are encapsulated in corrosion-resistant, double-encased capsules to ensure safety, durability, and performance under extreme operating conditions. Designed for compatibility with Sentinel projector systems, they provide consistent radiographic results, extended service life, and full compliance with international safety and transport regulations.

Inquire Now
Download Brochure
Features
  • High gamma energy for deep material penetration
  • Encapsulated in double-welded stainless steel or titanium capsules
  • Long half-life for extended field use (Ir-192 and Co-60)
  • Stable and predictable emission characteristics
  • Available in various activity levels and configurations
  • Compatible with Sentinel cameras and exposure devices
  • ISO and IAEA transport certified (Type A/B(U) packages)
  • Minimal maintenance and long operational lifespan
Applications
  • Pipeline weld inspection
  • Pressure vessel testing
  • Power plant maintenance
  • Offshore oil and gas infrastructure
  • Heavy fabrication radiography
  • Aerospace and defense inspections
  • Castings and structural component evaluation
Technical Data
Parameter Iridium-192 Cobalt-60
Radiation Type Gamma Gamma
Typical Photon Energy 317–612 keV 1.17 MeV & 1.33 MeV
Half-Life 73.8 days 5.27 years
Capsule Material Stainless steel or titanium Stainless steel or titanium
Activity Range Up to 150 Ci (5.55 TBq) Up to 100 Ci (3.7 TBq)
Typical Use Medium-density materials High-density materials
Compliance Standards ISO 2919, ISO/IEC, IAEA regulations ISO 2919, ISO/IEC, IAEA regulations
Transport Certification Type A/B(U) containers Type B(U) containers
  • Tags: Cobalt-60, gamma emission source, gamma source, industrial radiography, Iridium-192, NDT isotope, non-destructive testing, pipeline inspection, sealed radioactive source, Sentinel compatible source, Type B container, weld radiography

Tags:

Metals Testing, Radioactive Source, Radiographic Testing
