KR2000 (Chino) Series graphic recorder

Graphic Recorder

The KR2000 Series by Chino is a high-performance, network-connected paperless graphic recorder featuring a crisp 5.6-inch TFT color LCD for clear real-time and historical visualization, ultra-fast sampling at ~100 ms, and excellent ±0.1 % accuracy; it supports versatile inputs, extensive on-board and CF-card data storage, remote monitoring via browser, FTP, and email alerts—combining ease of use with industrial reliability for precision recording.

Features

High-visibility 5.6″ TFT color LCD display
Network-compatible: web browser monitoring, FTP transfer, e-mail notification
Ultra-fast sampling rate (~100 ms)
High measurement accuracy (±0.1 % FS)
Wide variety of universal inputs (DC voltage, thermocouples, RTDs)
Data storage: internal memory + up to 8 GB CF card
USB port (front) for USB memory/PC connectivity
Built-in computation (arithmetic, comparison, logical)
Optional: alarm outputs, PLC communication, custom graphics via KR Screen Designer

Applications

Electricity/Electronics/Components measurement and control
Education and R&D (universities, vocational schools)
Calibration and metrology environments

Technical Data

Specification	Value / Details
Display	5.6″ TFT color LCD
Sampling Interval	~100 ms (multi-input models)
Accuracy	±0.1 % FS
Input Types	Universal (DC voltage, thermocouples: B, R, S, K, etc.; RTD: Pt100, etc.)
Measurement Points	6 or 12 points depending on model
Data Storage	Internal memory + up to 8 GB CF card
Network Capabilities	Web monitoring, FTP transfer, email notifications
USB Connectivity	Front-panel USB port (supports 8 GB USB memory or PC)
Computation Functions	Arithmetic, comparison, logical
Optional Features	Alarm outputs, PLC communication, custom graphic screens via designer software
